V5624G Enterprise-class Standalone Switch

V5624G is an enterprise-class standalone switch with 1U form factor for data center, campus and branch office environments.

This switch offers 24 1Gigabit Ethernet ports (RJ-45/SFP) and provides high-bandwidth switching, filtering, and traffic management without delaying data.

V5624G include LLDP (Link Layer Discovery Protocol) which allows for troubleshooting and enhanced network management over multi-vendor environments, as well as LLDP-MED and DHCP Snooping to further expand network security.

V5624G provides 2 PSU (Power Supply Unit) slots that AC power module can be mounted.

This ensures equipment-level reliability with power module redundancy architecture.

WEIGHT & DIMENSION

Size (W x H x D)

• 440 x 44 x 325mm

POWER

Input

• AC : 100~240VAC (50/60Hz)

• DC : -20~-60VDC

Power Consumption

• Max. 61W

INTERFACES

Service Port

• 24 Port  1GbE combo (RJ45, SFP)

Network Port

• 4 Port  1G/10GBase-R (SFP/SFP+)

Console Port

• 1 Port (RJ45 to RS232)

MGMT Port

• 1 Port (RJ45)

• 1 Port (RJ45)

PROTOCOL SUPPORT

Layer 2

• Standard Ethernet Bridging

• Port/Subnet/Protocol-based VLAN

• Spanning tree (STP/ RSTP/ MSTP)

• Link aggregation: Static, LACP

• DHCP server/relay/option82

• Port Mirroring

• GARP/GVRP

• EFM-OAMDHCP Relay

Layer 3

• IPv6 support

• ECMP

• OSPF, BGP, VRRP

• PBR

• VRF

• BFD

Multicast

• IGMPv1/v2/v3, PIM-SM/SSM

• IGMP snooping/proxy

QoS

• Smart Buffer

• 8 queues per port

• WDRR/SP

• 802.1p/DSCP

• Shaping at Egress

• Remarking

Security

• 802.1x

• Radius/TACAS+

• Martian filter

• DAI

MANAGEMENT

Interfaces

• SNMP/Telnet/TFTP/SSH/SFTP

• Syslog volatile, nonvolatile, remote

• RMON

OPERATING REQUIREMENTS

Operating Temperature

• -20 ~ 60°C

Storage Temperature

• -40 ~ 80°C

Humidity

• 0 ~ 90% (non-condensing)
