WEIGHT & DIMENSION
Size (W x H x D)
- 440 x 44 x 230 mm
POWER
Input
- AC : 100-240VAC (50/60Hz)
Power Consumption
- Max. 14W
INTERFACES
Service Port
- 24 Port 10/100/1000Base-T (RJ45)
Uplink Port (Combo)
- 4 Port 1000Base-X (SFP)
- 4 Port 1000Base-T (RJ45)
Console Port
- 1 Port RS232(RJ-45)
MGMT Port
- 1 Port 10/100Base-TX(RJ-45)
PROTOCOL SUPPORT
L2 Features
- Standard Ethernet Bridging
- Port/Subnet/Protocol Based VLAN
- 8K MAC Address Entries
- 4K VLANs
- Jumbo Frame 10K
- STP/RSTP/MSTP/PVSTP/PVRSTP
- 802.3ad link Aggregation
- Port Mirroring
Security & QoS
- Ethernet Type/ L4-Based ACL
- SSH v1/v2
- 4 Queues per Port
- Conditional Rate Limiting
Multicast
- IGMP v1/v2/v3
- IGMP Snooping
- Multicast VLAN Registration(MVR)
MANAGEMENT
Interface
- Serial/Telnet(CLI)
- SNMP v1/v2/v3
- Multicast
- RMON
OPERATING REQUIREMENTS
Operating Temperature
- 0℃ ~ 50℃
Storage Temperature
- -40℃ ~ 70℃
Humidity
- 5% ~ 95% (non-condensing)
