Specifications meet or higher than Chinese National Standards, Can produce specified products with higher standard based on user’s requirement.
High quality printed circuit board for RF applications.
Using high quality, chip resistors & chip capacitors.
Specification:
|
NO. |
ITEM |
Frequency (MHz) |
2-way |
|
1 |
Insertion loss (dB) |
5-65 65-550 550-750 750-1000 |
≤4.0 ≤4.2 ≤4.5 ≤5.1 |
|
2 |
Isolation (dB) |
5-10 10-65 65-750 750-1000 |
≥27 ≥27 ≥27 ≥25 |
|
3 |
Return loss IN/OUT (dB) |
5-10 10-550 550-750 750-1000 |
≥16 ≥16 ≥16 ≥16 |
|
4 |
connection |
3/8-32UNEF(F-female) |
|
|
5 |
RFI(dB) |
≥100 |
|
|
6 |
Impedance |
75Ω |
|
