Specifications
|
Performance |
Test method |
specification |
||
|
Physical Properties |
Tensile strength(MPa) |
GB/T1040 |
≥10.4 |
|
|
Elongation(%) |
GB/T1040 |
≥200 |
||
|
Tensile strength after aged(MPa) |
UL224;158℃X168h |
≥7.3 |
||
|
Elongation at break after(%) |
UL224;158℃X168h |
≥100 |
||
|
Heat shock |
UL224;250℃X4h |
NO Melting, NO Breakdown |
||
|
Low temperature Flexibility |
UL224;-30℃X1h |
NO Breakdown |
||
|
Pell off strength to polyolefin. |
ASTM D1000 |
30pli(110N/25mm) |
||
|
Pell off strength to aluminium |
ASTM D1000 |
20pli(80N/25mm) |
||
|
Electrical Properties |
Voltage |
300v |
UL224 |
1500V, NO Breakdown |
|
600v |
UL224 |
2500V, NO Breakdown |
||
|
Disruptive Strength(KV/mm) |
GB/T1408 |
≥15 |
||
|
Volume Resistivity(Ω.cm) |
GB/T1410 |
≥1x1014 |
||
|
Chemical Properties |
Copper Corrosion |
UL224;158℃X168h |
PASS |
|
|
Corrosion Resistance |
UL224;158℃X168h |
PASS |
||
|
Fungus Resistance |
UL224 |
* |
||
