Applications:
Telecommunications
Local area network
FTTH deployments
Video transmission
Fiber optic sensing
Testing instruments
Describe Product
Specifications
Performance Specifications:
|
Characteristics |
Unit |
Value/Performance |
|
Center Wavelength (dual window) |
nm |
1310 and 1550 |
|
Bandwidth (wideband) |
nm |
± 40 |
|
Excess Loss |
dB |
≤ 0.15 |
|
Uniformity |
dB |
≤ 1.0 |
|
Insertion Loss ( without connector loss) |
dB |
≤ 5.5 |
|
Polarization Stability/Polarization Dependent Loss |
dB |
≤ 0.3 |
|
Thermal Stability |
dB/°C |
≤ 0.2 peak-peak |
|
Return Loss |
dB |
≥ 50 |
|
Lead Length |
m |
1, others on request |
|
Lead Type |
- |
900 μm loose tube, fiber from Corning/US, LS/Korea or brand from G7/EU |
|
Connector |
- |
SC/APC (4 ends. Ferrule material: ceramic) |
