Applications:
Telecommunications
Local area network
FTTH deployments
Video transmission
Fiber optic sensing
Testing instruments
CATV
Describe Product
Specifications
Specifications:
|
Characteristics |
Unit |
Value/Performance |
|
Center Wavelength (dual window) |
nm |
1310 and 1550 |
|
Bandwidth (wideband) |
nm |
± 40 |
|
Excess Loss |
dB |
≤ 0.08 typ. |
|
Uniformity (50:50) |
dB |
≤ 0.8 |
|
Max. Insertion Loss ( without connector loss) |
dB |
3.6 / 3.6 (50% / 50%)
|
|
Polarization Stability/Polarization Dependent Loss |
dB |
≤ 0.1 |
|
Thermal Stability |
dB/°C |
≤ 0.2 peak-peak |
|
Directivity |
dB |
≥ 50 |
|
Reflectance |
dB |
≥ 50 |
|
Lead Length |
m |
1, others on request |
|
Lead Type |
- |
900 μm loose tube, fiber from Corning/US, LS/Korea or brand from G7/EU |
|
Connector |
- |
SC/APC (3 ends. Ferrule material: ceramic) |
