Specification：
|
NO |
ITEM |
Frequency (MHz) |
Value of Tap(dB) |
|||||||||
|
-12 |
-14 |
-16 |
-18 |
-20 |
-22 |
-24 |
-26 |
-28 |
||||
|
1 |
Tap Loss （dB） |
5-65 65-750 550-750 750-1000 |
±1.0 ±1.0 ±1.0 ±1.5 |
±1.0 ±1.0 ±1.2 ±1.8 |
±1.0 ±1.0 ±1.0 ±1.5 |
|||||||
|
2
|
Insertion Loss (dB) |
5-65 65-550 550-750 750-1000 |
- - - - |
≤3.6 ≤3.8 ≤4.0 ≤4.4 |
≤2.6 ≤2.8 ≤3.2 ≤3.6 |
≤2.2 ≤2.2 ≤2.4 ≤2.6 |
≤1.4 ≤1.4 ≤1.6 ≤1.8 |
≤1.0 ≤1.2 ≤1.4 ≤1.6 |
≤0.9 ≤1.0 ≤1.2 ≤1.4 |
≤0.8 ≤1.0 ≤1.2 ≤1.4 |
≤0.7 ≤0.8 ≤1.0 ≤1.2 |
|
|
3 |
Isolation Out-Tap (dB) |
5-65 65-550 550-750 750-1000 |
- - - - |
≥30 ≥30 ≥28 ≥26 |
≥30 ≥30 ≥28 ≥26 |
≥32 ≥30 ≥28 ≥26 |
≥32 ≥32 ≥30 ≥28 |
≥32 ≥32 ≥30 ≥28 |
≥35 ≥35 ≥32 ≥30 |
≥40 ≥35 ≥32 ≥32 |
≥40 ≥38 ≥35 ≥32 |
|
|
4 |
Isolation Tap-Tap (dB) |
5-65 65-550 550-750 750-1000 |
≥26 ≥26 ≥26 ≥25 |
|||||||||
|
5
|
Return IN/OUT (dB) |
5-65 65-550 550-750 750-1000 |
≥18 ≥18 ≥18 ≥18 |
|||||||||
|
6 |
Return TAP (dB) |
5-65 65-550 550-750 750-1000 |
≥18 ≥20 ≥18 ≥18 |
|||||||||
|
7 |
Connection |
3/8-32UNEF |
||||||||||
|
8 |
RFI(dB) |
≥100 |
||||||||||
|
|
|
|||||||||||
